Related Categories

Specification

BrandMarley
Stocking BranchesBrighouse, Huddersfield, Leeds, Penistone
Product TypeRoof Tile
Size267 x 168mm
Thickness12mm
ColourGrey

Marley Concrete Plain Roof Tile Smooth Grey 267 x 168mm

£0.81 exc. VAT

Postcode Check
Enter your postcode to find nearby stores and to check if we can deliver to you.
SKU: 26134
MPN: MA14028
EAN: 5030572082963
marley
Manufacturer / Supplier
About Marley

Marley is a leading UK manufacturer of roofing solutions, offering a comprehensive range of high-performance products designed for both traditional and contemporary projects. Their selection includes clay and concrete roof tiles, such as the classic Acme Single Camber Plain Tile and the versatile Modern interlocking tile, available in various colours and finishes to suit diverse architectural styles. For those seeking sustainable options, Marley provides the SolarTile®, an integrated solar panel system that combines energy efficiency with aesthetic appeal.

Beyond tiles, Marley offers a complete roofing system encompassing underlays, battens, dry fix systems, and ventilation accessories, all engineered for compatibility and ease of installation. This holistic approach ensures durability, compliance with UK building standards, and peace of mind through a 15-year system guarantee. Whether undertaking a new build or a refurbishment, Marley’s extensive product range and commitment to quality make them a reliable choice for roofing projects.

Brochures

Specification

BrandMarley
Stocking BranchesBrighouse, Huddersfield, Leeds, Penistone
Product TypeRoof Tile
Size267 x 168mm
Thickness12mm
ColourGrey

Product Description

A classic concrete plain tile that stands the test of time: perfect for classic pitched roof designs, such as dormer and eyebrow windows.

Specifications

Size of Tile 267 x 168mm
Minimum Pitch* 35°
Maximum Pitch 90°
Minimum Headlap 65mm (Roof)
37.5mm (Vertical)
Maximum Gauge 100mm (Roof)
115mm (Vertical)
Tile Thickness 12mm (Nominal)
Cover Width 168mm (Nominal)
Covering Capacity (Net) 60 tiles/m² at 100mm Gauge (Roof)
53 tiles/m² at 115mm Gauge (Vertical)
Weight of Tiling (Approx.) 73.8kg/m² (0.72 kN/m²) at 100mm Gauge (Roof)
58kg/m² (0.57 kN/m²) at 115mm Gauge (Vertical)
Battens Required (Net) 10 lin.m/m² at 100mm Gauge (Roof)
8.7 lin.m/m² at 115mm Gauge (Vertical)
Batten Size Recommended 38 x 25mm for rafters/supports not exceeding 600mm centres (Fixed to BS 5534)
Tile Nails 38 x 2.65mm
Authority BS EN 490

*The minimum recommended pitch and lap may be influenced by special circumstances.

Sustainability

  • A+ rated in the BRE Green Guide (Based on generic rating for UK produced concrete plain tiles Element Refs: 812410017, 812410050, 812410064).
  • BES 6001 Responsible Sourcing Certified.
